Standard Manual Lathe
Your Professional Standard Manual Lathe Supplier！
Anyang Xinsheng machine tool China's earliest batch of production of large-scale lathe specialized manufacturers, factory history of 80 years. Our Product: Conventional horizontal lathe series, Heavy-duty horizontal lathe series (10 tons, 16 tons, 32 / 63 tons, etc.), Economical CNC horizontal lathe series, Full-function CNC horizontal lathe series, Spherical conventional horizontal lathe, CNC vertical lathe, Pipe thread CNC lathe, Turning and milling compound machining centers, Automated production lines, Special-purpose or customized machine tools.
Why Choose Us
Advanced Equipment
Our factory is equipped with advanced production equipment, including precision CNC gantry grinders, horizontal and pentahedron machining centers, dual spindle gantry milling machines, high-precision coating equipment, digital universal tool microscopes, and coordinate measuring machines.
Honors and Awards
Many of our products have repeatedly won the "Chunyan Award" from the China Machine Tool & Tool Builders' Association, as well as national key new product awards, the Science and Technology Progress Award of the Machinery Industry, the Henan Provincial Science and Technology Progress Award, the Henan Provincial Industry and Information Technology Achievement Award, and the Anyang Science and Technology Progress Award.
Quality Control
Our factory employs state-of-the-art machinery and rigorous quality control processes, ensuring high precision, repeatability, and consistent performance for all products.
A standard manual lathe is a conventional machine tool that rotates a workpiece on an axis against a stationary cutting tool to perform operations like turning, facing, threading, and drilling. Operated by hand, it offers high control and tactile feedback, making it ideal for repairs, prototyping, and small-batch production.
Product Specification
We offers the following product specifications:
|
ITEM |
UNIT |
CW6180 |
CW61100 |
|
CAPACITIES |
|||
|
Swing over bed |
mm |
800 |
1000 |
|
Swing over carriage |
mm |
480 |
680 |
|
Max.length of workpiece |
mm |
1500 2000 3000 4000 5000 6000 |
|
|
Max.turning length |
mm |
1350 1850 2850 3850 4850 5850 |
|
|
Pan of guideway |
mm |
600 |
|
|
SPINDLE |
|||
|
Spindle nose |
mm |
C11 (C15 optional) |
|
|
Spindle bore |
mm |
100 (140 optional) |
|
|
Taper hole of spindle |
|
1:20 |
|
|
Range of spindle speeds |
r/min |
forward: 6~750 reverse: 10~775 |
|
|
No.of spindle speeds |
|
18/6 |
|
|
FEED |
|||
|
Longitudinal and cross |
|
64; 0.1~24.32 |
|
|
Cross/long longitudinal feed |
|
1/2 |
|
|
Screw pitch of leadscrew |
mm |
12 |
|
|
No. and range of metric thread |
|
50; 1~240 |
|
|
No. and range of inch thread |
|
26; 14~1 |
|
|
No. and range of module thread |
|
53; 0.5~120 |
|
|
No. and range of dia. thread |
|
24; 28~1 |
|
|
Rapid traverse speed |
mm/min |
4000 |
|
|
TURRET |
|||
|
Distance of spindle and tool plane |
mm |
33 |
|
|
Tool post swing range |
° |
±90° |
|
|
Max.travel of cross slide |
mm |
500 |
|
|
Max.travel of top slide |
mm |
200 |
|
|
Section of tool shank |
mm |
32 (202x202) |
|
|
TAILSTOCK |
|||
|
Dia. of tailstock |
mm |
100 |
|
|
Travel of tailstock quill |
mm |
250 |
|
|
Taper hole of tailstock quill |
|
morse6 |
|
|
OTHERS |
|||
|
Main motor power |
kw |
11 |
|
|
Length |
mm |
3670 3985 5165 6220 7400 8260 |
|
|
Width |
mm |
1730 |
|
|
Height |
mm |
1450 |
|
Product advantages
Cost-effectiveness: Conventional lathe machine are generally more affordable than CNC lathes. They have simpler designs and do not require sophisticated electronic controls and programming associated with CNC machines.
Versatility: Manual toolroom lathe machine are highly versatile and can perform a wide range of machining operations. They can handle tasks such as turning, facing, drilling, boring, threading, and tapering.
Flexibility and Adjustability: Operators have full control over the cutting tool and the machining process in a conventional lathe machine. They can easily adjust the speed, feed rate, depth of cut, and tool position according to the specific requirements of the workpiece.
Skill Development: Operating a conventional lathe requires a certain level of skill and craftsmanship. Machinists who work with manual toolroom lathe develop a deep understanding of the machining process, tooling, and work-holding techniques.
Maintenance and Repair: Conventional lathes have simpler mechanical systems compared to CNC lathes machines, which can make them easier to maintain and repair. Their components and mechanisms are generally more accessible, and repairs or replacements can often be done without specialized knowledge or expensive components.
Application
Aerospace Industry
Manual lathes play a crucial role in the aerospace industry for machining large and intricate components such as landing gear parts, turbine shafts, and engine components.
Oil and Gas Sector
In the oil and gas industry, manual lathes are employed to manufacture components used in drilling and exploration equipment. These lathes are capable of handling the machining of heavy-duty parts like drill collars, flanges, and pipeline components with precision, contributing to the reliability and efficiency of the equipment.
Automotive Manufacturing
They are widely used in the automotive industry for the production of critical components such as crankshafts, axles, and transmission parts. The lathes' ability to handle large workpieces and perform various machining operations in a single setup makes them ideal for the demands of automotive manufacturing.
Railway Manufacturing
They are utilized in the railway industry for machining components such as wheel hubs, axles, and couplings. The lathes' capacity to handle large and heavy workpieces ensures the production of durable and reliable railway components.
Ways – The flat or V-shaped bearing surfaces that align and guide the moving parts of the machine
Carriage – The assembly that moves along the ways and supports the tool post
Headstock – The end of the lathe that holds the spindle and the drive that rotates the workpiece
Tailstock – The device at the end of a lathe that uses either a live center or a dead center to support longer workpieces while they are being machined
Bed – The foundation of the entire machine that holds the headstock, tailstock and carriage in alignment
Saddle – The casting that fits onto the top of the bed and slides along it
Apron – The often flat and rectangular box that contains the drive mechanism for the machine’s power feed
Compound Rest – Consists of the top slide and the cross slide that are used for angular movement
Tool Post – Mount for various types of cutting tools
Lead Screw – A long, threaded rod normally found running along the front of the bed that transmits power to the carriage using a gear arrangement
Other Services
All of our machines will be fully checked by our quality control department before the shipment. We guarantee all of our laser machines have a one-year warranty (quick-wear parts not included).
Training details: operation principles, system, and structure, safety and maintenance, software processing technique, etc.
Numerous feedback from our clients have proven that our laser machines are stable in performance with rare malfunction. However, we would like to handle it as follows once malfunction occurs:
a.We guarantee that we will give you a clear reply within 24 hours.
b.Customer service staff will assist you in analyzing the malfunction to locate the cause.
c.If the malfunction is caused by improper operation of software and other soft faults, we will help solve the problem online.
d.We will offer plenty of online support, like detailed technical and installation instructions via email, video, and telephone.
Package & Delivery
1. Package: Standard export package or Custom
2. Delivery: By air express, by sea
FAQ
As one of the leading standard manual lathe manufacturers and suppliers in China, our products have good reputation in the market. Please feel free to buy high quality standard manual lathe made in China here from our factory. For price consultation, contact us.
